Pneumatic Actuator Riam Rooj Vag Valve

Cov Lus Qhia Paub Khoom

NSV Pneumatic riam lub rooj vag valve, nws txhais tau hais tias pneumatic actuator tswj cov li qub qhib thiab kaw, uas muaj qhov seem thiab ntu ntu, ntu ib feem yog actuator, seem ib feem yog riam rooj vag valve.

Pneumatic riam rooj vag valve muaj qhov zoo ntawm cov qauv yooj yim thiab compact, tsim qauv tsim nyog, lub teeb txuag khoom, txhim khu kev qha, ua haujlwm yooj yim, ntim me me, cov lus hla, tsis ntws tsis kam, lub teeb nyhav, yooj yim rau nruab, yooj yim rau kev cuam tshuam thiab lwm yam. Nws tuaj yeem ua haujlwm nquag nyob rau hauv kev ua haujlwm siab ntawm 1.0MPa-2.5MPa thiab kev ua haujlwm ntawm -29-650 temperature. Riam-hom lub rooj vag valve muaj qhov ua haujlwm ntawm kev txiav, uas tuaj yeem txhuam tawm cov nplaum rau ntawm qhov chaw sealing thiab tshem tawm qhov sundries txiav. Lub rooj vag hlau stainless tuaj yeem tiv thaiv kev sib khi to los ntawm kev xeb.

Muaj Qauv Siv
Tus Qauv Tsim: MSS SP-81, ANSI, API, ISO, DIN, EN, JIS thiab lwm yam.
Xaus Flange: ASME B16.5, ASME B16.47, DIN2533

Ntau Yam Khoom
Loj: 2 "txog 48" (DN50 rau DN1200, cov taub loj ntawm kev thov)

Flange Kev Txuas

EN1092 PN10, PN16, PN25
ANSI B16.5 (chav kawm 125,150)

Cov Khoom Siv
Cov Khoom Siv Lub Cev: Zas Hlau, Cov Hlau Hlau, Hlau Hlau thiab Cov Hluav Taws Xob Tshwj Xeeb
Qhov Rooj Riam: Cov Hlau Stainless, Duplex thiab Alloys Tshwj Xeeb

Lub Rooj: Resilient (EPDM, NBR, PTFE) lossis Hlau Rooj Tog
Kev Ua Haujlwm: Pneumatic actuator.

Ceev Faj Txog Kev Ntsuas

Txoj Haujlwm Valve

Lub valve tuaj yeem sib dhos rau hauv ib txoj haujlwm twg, txawm li cas los peb pom zoo kom haum txoj haujlwm raws li nqov:

Riam rooj vag valve sib dhos txoj kev

Lub valve yog unidirectional yog yuav tsum tau nruab nrog lub siab uas thawb rab riam ntawm lub gasket.Qhov kev taw qhia ntws yog cov neeg siv lub luag haujlwm.Phov muab qhov sib dhos ua ke raws li tus xub taw ntawm lub cev (daim ntawv thov hydraulic).

Kho thiab Txij Nkawm

Coj cov laus tawm

Tso 3 txheej ntawm ntim rau hauv qhov chaw

Nco ntsoov tias txhua qhov sib koom tes ntawm cov pob khoom yuav tsum nyob rau ntau qhov chaw

Hloov chaw ntawm lub rooj zaum valve

A.Unscrewed packing gland thiab tshem tawm lub rooj vag

B.Remove retainer nplhaib

C.Thaiv EPDM qub ntiv nplhaib tawm thiab ntxuav nws qhov chaw

D.Put ntiv nplhaib EPDM tshiab rau hauv qhov chaw

E.Put ra racerer ntawm EPDM nplhaib

F.Put rooj vag rov qab thiab ntim hauv lub cev valve

G. Muab sib dhos ntim khoom ntawm lub caj pas thiab muab cov ntsia hlau kom nruj

Cov FAQ

1.Q: Dab tsi yog hom ntawm koj lub tuam txhab tsim khoom?

A: NSV lossis OEM kev pabcuam

2. Q: Koj lub tuam txhab puas muaj tus neeg sawv cev / xa tawm tshwj nrog Suav?

A: Tam sim no, peb muaj tus neeg sawv cev hauv Indonesia, Singapore, Canada, Mexico, Iraq, thiab txais tos hu rau peb yog tias koj xav koom nrog peb.

3. Q: Koj puas yog cov chaw tsim khoom lossis chaw lag luam?

A: Peb nyob nraum chaw tsim khoom, tab sis peb lub Hoobkas tsis muaj npe NSV vim peb txawj ua haujlwm NSV hom nrog cov kev pabcuam zoo tshaj plaws, thiab tseem tau muag rau ntau tus neeg siv khoom tiav.

Cim npe nrov: pneumatic actuator riam lub rooj vag valve, Tuam Tshoj, tuam ntxhab, lwm tus muag khoom, lub Hoobkas, ua nyob rau hauv Suav teb
